GLARO Engineering: Structures

Below is a gallery of the wetland restoration structures designed, installed and implemented by Ducks Unlimited's Great Lakes/Atlantic Regional Office engineering staff.

These photos are merely a sample of the diverse work the Great Lakes/Atlantic Region engineers do every year. Contact Warren Weirich at (734) 623-2000 for details.



Back Bay National Wildlife Refuge, Virginia

Fishing pier with boat ramp

Crane Lake, Illinois

Six-bay sheet pile structure



Erie National Wildlife Refuge, Pennsylvania

Fixed crest structure with beaver guard



Close-up of beaver guard


Lackey Pond, Massachusetts

Concrete weir dam



Montezuma Wetland Complex, New York

Structure installation



Linton, Indiana

Water control structure with float cutoff



Aerial of macro topography



Moosehorn, Maine

Six-bay structure with fish ladder - Upstream



Six-bay structure with fish ladder - Downstream



Patuxent National Wildlife Refuge, Maryland

Structure retrofit with shoreline protection



Prime Hook National Wildlife Refuge, Delaware

Ten-bay weir gate system



Rush Lake, Wisconsin

Sheet pile weir with water control gates

Railcar bridge



Spring Lake, Illinois

Four-way water control structure with gates
